NEWMEN - Rim - Evolution SL A.30

Overview

Like all NEWMEN EVOLUTION SL components, this rim is constructed from high-strength aluminium alloy for outstanding mechanical properties combined with a low weight. The flared flanges make it particularly hard-wearing against dents and deformation whilst keeping the tire rounder for more cornering grip. Materials are deployed precisely at critical points and shaved off elsewhere. The flat spoke bed is designed to work with our special washers for extremely high spoke tension values whilst keeping the amount of material used down to a minimum. In contrast, the flanges are substantially thicker than on other rims in the same weight class for added strength and durability. The perfect rim for a wide, lightweight and fast all-mountain wheelset that fits tires from 2.35" up to 2.6".

Specifications

Model Family	Evolution SL
Inner Width	30mm
Intended Use	Trail
Material	Aluminium
Rim Profile	Hookless Tubeless Ready
Max System Weight	150kg
Spoke Hole Number	28h / 32h
Washer Required	Yes
Weight	480g / 510g
Eyelets	No
Diameter	27.5",29"
